sZ錐雙螺桿擠出機專用齒輪箱

Special Decelerator for sZ Conic Double-screw Extruder

一、原理及概述Principle and overview

SZ錐雙螺桿擠出機傳動裝置是與錐雙螺桿塑料擠出機配套的專用機械傳動裝置，該裝置可把主電機的動力經過傳動箱減速增扭后輸出至分配箱長軸，長軸再通過一對1:1傳動比的小錐角螺旋齒輪，帶動短軸。長.短軸以螺桿相同的夾角，以異向外旋的方式帶動螺桿擠出成型。傳動箱采用硬齒面標準設計.齒輪經滲碳淬火磨齒，精度達6級，所有油封皆采用進口產品.傳動箱和分配箱內皆配有冷卻水管，用于潤滑冷卻。由于產品齒輪精度高，噪音低，承載能力強，軸承配置相對傳統產品有新的改進，因而其總體性能指標優于現行產品。

SZ cone double-screw extruder gearing is a special mechanical driving device matched with conicdouble-screw plastic extruder. This advice decelerates and increases the torque of the power from master motor through gearbox before exporting it to the long shaft of distribution box that drives short shaft through a slender cone screw gear with drive ratio of 1:1, long shaft and short shaft drive screw at the same angle as screw to extrude and mould in the mode of different direction and outward turning. Gearbox is designed with hard tooth surface standard,and gear wheel is treated with carburation and quenching and grinding to achieve the precision of class 6,all of the oil seal is imported products,both gearbox and distribution box are equipped with cooling pipe for lubrication cooling Gear wheel is of high precision,low noise,and high carrying capacity ,resulting in a relatively improved bearing configuration in comparison with traditional one, therefore, the general performance is superior to that of current products.

4.使用條件Service condition

4.1傳動箱高速軸轉速不大于1500r/min; Rotate speed of gearbox high-speed shaft is≤1500r/min

4.2工作環境溫度0-35°C Ambient temperature for service is 0-35'C

5.冷卻與潤滑Cooling and lubri cation

5.1冷卻Cooling

傳動箱和分配箱皆采用水冷卻，冷卻水溫應低于30"C

Both gearbox and distribution box apply water cooling with temperature lower than 30'C

5.2潤滑Lubrication

齒輪和軸承皆采用油池潤滑，潤滑油推薦牌號為中極壓齒輪油N220-320.

Both gear wheel and bearing apply oil sump lubrication and recommended brand of lubricant is mild extreme pressure gear grease N220-320.

本廠擁有對本說明書的解釋權，若有疑問請與本廠技術部門聯系。一般每年一版， 選用時請以***新版本為準。

The manufacturer has the right to interpret this instruction book, and any questions may refer to our technical department.

This instruction book is updated every year, so the latest edition should be identified for reference.
